Product Summary
The G121SNO1 is a dual rail-to-rail input and output single-supply amplifier featuring 100mA output drive current. This high output current makes these amplifiers excellent for driving either resistive or capacitive loads. AC performance is very good with 3.5MHz bandwidth, 6.2V/μs-slew rate and low distortion. All are guaranteed to operate from a +3 volt single supply as well as a +5 volt supply.
Parametrics
G121SNO1 absolute maximum ratings: (1)Input Voltage: GND to VS; (2)Differential Input Voltage: ±6V; (3)Storage Temperature Range: -65°C to +150°C; (4)Operating Temperature Range: -40°C to +85°C; (5)Junction Temperature Range: -65°C to +150°C.
Features
G121SNO1 features: (1)Single-Supply Operation: 2.2 Volts to 6 Volts; (2)High Output Current: 100mA; (3)Wide Bandwidth: 3.5 MHz; (4)Slew Rate: 6.2 V; (5)No Phase Reversal; (6)Unity Gain Stable; (7)Rail-to-Rail Input and Output.
Diagrams
 |
