Product Summary
The GP430-EG11 is a Dual Switch IGBT Module. Application areas of the GP430-EG11 include High Reliability Inverters, Motor Controllers, Traction Drives.
Parametrics
GP430-EG11 absolute maximum ratings: (1)Collector-emitter voltage: 1200V; (2)Gate-emitter voltage:±20V; (3)Continuous collector current: 400A; (4)Peak collector current: 800A.
Features
GP430-EG11 features: (1)High Thermal Cycling Capability; (2)400A Per Switch; (3)Non Punch Through Silicon; (4)Isolated MMC Base with AlN Substrates.
Diagrams
 |
